AS/NZS4671 Standard Galvanized Welded Mesh Panels For Underground Supporting

Name: ASNZS4671 Standard Galvanized Welded Mesh Panels For Underground Supporting
Brand: X MESH
Price: 14.50 USD

Wholesale AS/NZS4671 Standard Galvanized Welded Mesh Panels For Underground Supporting from china suppliers

Brand Name : X MESH

Model Number : X MESH-Mine Mesh-010

Certification : ISO9001:2015

Place of Origin : Hebei P.R. China.

MOQ : 100PCS

Price : USD14.50-58.50/PC

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 58000PCS/WEEK

Delivery Time : 5-7days

Packaging Details : Wrapped with plastic film and pallet packing

Product Name : Galvanized Welded Mesh

Material : Galvanized Steel Wire

Wire Diameter : 6mm

Mesh Opening : 150mm x 150mm

Width : 2.4m

Length : 6.0m

Feature : Smooth surface & Anti-erosion

Application : for Understandground Supporting

Packing : Pallet or Wooden Case Packing

Standard : AS/NZS4671 Standard

Contact Now

AS/NZS4671 Standard Galvanized Welded Mesh Wire Panels Sheets for Underground Supporting

Galvanized Welded Mesh Introduction:

Mine Welded Wire Mesh support is a kind of support method in deep foundation pit support project. It is the shortened form for joint support of shotcrete, bolt and steel mesh, as an advanced support and reinforcement technology, in rock soil high slope and large span underground works, especially under adverse geological conditions, extensive and successful applicated at home and abroad.

Product Name	Galvanized Welded Mesh
Material	Galvanized Steel Wire
Wire Diameter	6mm
Mesh Opening	150mm x 150mm
Width	2.4m
Length	6.0m
Feature	Smooth surface & Anti-erosion
Application	for Understandground Supporting
Packing	Pallet or Wooden Case Packing
Standard	AS/NZS4671 Standard

Galvanized Welded Mesh Specification:

Mesh Panel Common Specification
Mesh		Wire Diameter
Expressed in Inches	limeters	Diameter	limeters
1" × 1"	25 mm × 25 mm	11 G - 14 G	2 mm - 3 mm
2" × 1"	50 mm × 25 mm	8 G - 14 G	2 mm - 4 mm
2" × 2"	50 mm × 50 mm	8 G - 14 G	2 mm - 4 mm
3" × 2"	75 mm × 50 mm	6 G - 14 G	2 mm - 5 mm
3" × 3"	75 mm × 75 mm	6 G - 14 G	2 mm - 5 mm
4" × 2"	100 mm × 50 mm	4 G - 14 G	2 mm - 6 mm
4" × 4"	100 mm × 100 mm	4 G - 14 G	2 mm - 6 mm
5" × 5"	125 mm × 125 mm	4 G - 14 G	2 mm - 6 mm
6" × 6"	150 mm × 150 mm	4 G - 14 G	2 mm - 6 mm
Max Width :2400mm , Max Length : 6000 mm
Note: Special specifications can be customized.

Mechanical Properties

Component	Strength	Standard
Wire	Tensile 500-750MPa	AS/NZS4671:2001
Weld Shear Strength		ISO15630-2
Galvanising		AS/NZS4534-2006

Galvanized Welded Mesh Feature:

High tensile strength

Smooth surface

Anti-erosion

anti-aging

anti-sunburn

Easy installation.

Galvanized Welded Mesh Application:

Slab on Grade reinforcement

Floor and Walls Systems

Topping Slabs

ArchiteFloor and Walls Systemsctural precast wall panels

Tilt-up construction wall systems

Shear walls

Retaining walls

Mechanically Stabilized Earth (M.S.E.) reinforcement

AS/NZS4671 Standard Galvanized Welded Mesh Panels For Underground Supporting
